FPV thermal camera CADDXFPV FT046 The CADDXFPV FT046 is a professional thermal camera designed for FPV drones, industrial monitoring and tactical applications. It is equipped with a vanadium oxide sensor with a resolution of 640×512 and a 9.1 mm F1.0 lens, which offers detailed thermal images and a wide field of view for an optimal overview of the situation. With 50fps frame rate, <20ms latency and CVBS analog output, the FT046 provides smooth real-time video transmission for low-latency FPV systems. Improved image processing (Allmage Enhancement) improves visibility in complex temperature conditions, which is ideal for night flights, search and rescue operations and inspection tasks. Specifications: Model: FT046 Sensor: uncooled vanadium oxide Resolution: 640 x 512 LENS: F1.0/9.1mm Field of view: 48.3° (H) * 38.6° (V) * 66° (D) Frame rate: 50 fps Power consumption: <1.5W Output: PAL Supply voltage: 9V ~ 24V Temperature: -20°C~60°C Interface: Analog interface: CVBS Latency: Average latency 20ms Image quality: Image enhancement The package contains: 1x FPV thermal camera CADDXFPV FT046
